300W Outdoor LED Advertising Board Waterproof Nova Controller 5500cd/m2

Place of Origin Shen Zhen China
Brand Name AVOE LED
Certification CE RoHS
Model Number AE-P5OFRGB
Minimum Order Quantity 5sqm
Price Negotiable
Packaging Details Flight case, Plywood case
Delivery Time 10 working days after receiving the payment
Payment Terms T/T, L/C, Western Union, MoneyGram
Supply Ability 10K sqm per month
Product Details
Name Outdoor LED Advertising Screen Pixel Pitch(mm) 5mm
Pixel Density(pixels/㎡) 40000 Brightness(nits) ≥6000
Tube Chip Color Full Color Warranty 5 Years
Module Size 320x160mm Certification CE,UL,CCC,ROHS,GS
Cabinet Size 960*960mm Input Voltage AC110V - AC240V
High Light

300W Outdoor LED Advertising Board

,

Nova Controller Outdoor LED Advertising Board

,

5500cd/M2 Waterproof LED Advertising Screen

Leave a Message
Product Description

Large advertising AVOE LED Display board video wall P5 waterproof cabinet Nova controller MSD600



Features



. Uniform color and high contrast ratio,bringing up fresh and natural image
· Low power consumption and fine heat release
· Super wide viewing angle increasing its value by covering more audience
· No deformation under sunlight by the use of anti-UV modules
· Long service time and low attenuation by applying duel channels for heat dissipation
· High protection grade of IP65 achieved by applying duel channels for heat dissipation
· High protection grade of IP65 achieved by patented mask design with waterproot and dustproof fucntion
· Safe and reliable operation ensured by stable signal nad power supply



Specification of P5 Outdoor Fixed LED Display


Specification of P5 Outdoor Fixed LED Display
Module
Dimention (w*h) 320mmx160mm Resolution (w x h) 64x32
Pixel pitch 5mm Pixel Density 40000 dots/㎡
Pixel Configration RGB 3-in-1 LEDs Type SMD1921 Nationastar Brand
Cabinet
Dimensions(w* h)(mm) 960*960mm Module Quantity(PCS) 18
Physical Resolution (w x h) 192*192 Physical Pixels (total) 36864
Weight/Cabinet (kg) 26kg Material Magnesium alloy
Average Power/㎡(watts) 300W Max Power/㎡(watts) 950W
Parameter Value
Brightness ≥ 5500cd/m2
Viewing Angle Horizontal 140(+70/-70) deg. Vertical 140(+70/-70)deg.
Best Viewing Distance 5-200meters
Brightness Control 256 level
Gray scale 14bits
Refresh frequency ≥ 1920Hz
Driving mode 1/8 scan constant current driving
Input power frequency 50/60 Hertz
Input Voltage AC/220 ~ 240 Volt
Blind spot rate <1/10000
Lifetime at 50% brightness 100000 hours
Ingress Protection IP65/IP54
Operating temperature ﹣20 ~﹢50 ℃
Operating humidity 10% ~ 90%
Control distance CAT6 cable:<100 m; Single mode fiber:<10 km
Signal input format AV, S-Video, VGA, DVI, YPbPr, HDMI, SDI
Operating system Windows (2007/XP/Vista/7/8/10)








Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to AVOE.

300W Outdoor LED Advertising Board Waterproof Nova Controller 5500cd/m2 0

300W Outdoor LED Advertising Board Waterproof Nova Controller 5500cd/m2 1300W Outdoor LED Advertising Board Waterproof Nova Controller 5500cd/m2 2

Competitive Advantages:

1. Good quality;
2. Good price;
3. Good 24hours service;
4. Promote delivery;
5. Energy-saving;
6. Small order accepted.

Our serrvices
1. Service before sales
On-site inspect
Professional design
Solution confirmation
Training before operation
Software use
Safe operation
Equipments maintenance
Installation debugging
Installation guidance
On-site debugging
Delivery Confirmation


2. After sale service
Quick response
Prompt question resolving
Service tracing

3. Service concept:
Timeliness, considerateness, integrity, satisfaction service.
We are always insisting on our service concept, and proud of the trust and reputation from our clients.

4. Service Mission
Answer any question; Deal with all the complaint; Prompt customer service
We had developed our service organization by responding to and meeting the diverse and demanding needs of customers by service mission. We had become a cost-effective, highly skilled service organization.

5. Service Goal:
What you have thought about is what we need to do well; We must and will do our best to fulfill our promise. We always bear this service goal in mind. We can't boast the best, yet we will do our best to free customers from worries. When you get problems, we had already put forward solutions before you.
