AC240V Outdoor LED Advertising Signs 5500cd/m2 960*960mm Aluminum Alloy
| Place of Origin | Shen Zhen China |
|---|---|
| Brand Name | AVOE LED |
| Model Number | AE-P5OFRGB |
| Minimum Order Quantity | 5sqm |
| Price | Negotiable |
| Packaging Details | Flight case, Plywood case |
| Delivery Time | 10 working days after receiving the payment |
| Payment Terms | T/T, L/C, Western Union, MoneyGram |
| Supply Ability | 10K sqm per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Certification | CE,UL,CCC,ROHS,GS | Name | Outdoor LED Advertising Screen |
|---|---|---|---|
| Pixel Pitch(mm) | 5mm | Pixel Density(pixels/㎡) | 40000 |
| Brightness(nits) | ≥6000 | Tube Chip Color | Full Color |
| Warranty | 5 Years | Module Size | 320x160mm |
| Cabinet Size | 960*960mm | Input Voltage | AC110V - AC240V |
| High Light | AC240V Outdoor LED Advertising Signs,5500cd/M2 Outdoor LED Advertising Signs,Aluminum Alloy Led Outdoor Advertising Board |
||
Product Description
P5 outdoor LED advertising signs 960*960mm aluminum alloy cabinet Novastar controller LVP615 Video processor
Features
. Uniform color and high contrast ratio,bringing up fresh and natural image
· Low power consumption and fine heat release
· Super wide viewing angle increasing its value by covering more audience
· No deformation under sunlight by the use of anti-UV modules
· Long service time and low attenuation by applying duel channels for heat dissipation
· High protection grade of IP65 achieved by applying duel channels for heat dissipation
· High protection grade of IP65 achieved by patented mask design with waterproot and dustproof fucntion
· Safe and reliable operation ensured by stable signal nad power supply
| Specification of P5 Outdoor Fixed LED Display | |||||
| Module | |||||
| Dimention (w*h) | 320mmx160mm | Resolution (w x h) | 64x32 | ||
| Pixel pitch | 5mm | Pixel Density | 40000 dots/㎡ | ||
| Pixel Configration | RGB 3-in-1 | LEDs Type | SMD1921 Nationastar Brand | ||
| Cabinet | |||||
| Dimensions(w* h)(mm) | 960*960mm | Module Quantity(PCS) | 18 | ||
| Physical Resolution (w x h) | 192*192 | Physical Pixels (total) | 36864 | ||
| Weight/Cabinet (kg) | 26kg | Material | Magnesium alloy | ||
| Average Power/㎡(watts) | 300W | Max Power/㎡(watts) | 950W | ||
| Parameter | Value | ||||
| Brightness | ≥ 5500cd/m2 | ||||
| Viewing Angle | Horizontal 140(+70/-70) deg. Vertical 140(+70/-70)deg. | ||||
| Best Viewing Distance | 5-200meters | ||||
| Brightness Control | 256 level | ||||
| Gray scale | 14bits | ||||
| Refresh frequency | ≥ 1920Hz | ||||
| Driving mode | 1/8 scan constant current driving | ||||
| Input power frequency | 50/60 Hertz | ||||
| Input Voltage | AC/220 ～ 240 Volt | ||||
| Blind spot rate | ＜1/10000 | ||||
| Lifetime at 50% brightness | 100000 hours | ||||
| Ingress Protection | IP65/IP54 | ||||
| Operating temperature | ﹣20 ～﹢50 ℃ | ||||
| Operating humidity | 10％ ～ 90％ | ||||
| Control distance | CAT6 cable:＜100 m; Single mode fiber:＜10 km | ||||
| Signal input format | AV, S-Video, VGA, DVI, YPbPr, HDMI, SDI | ||||
| Operating system | Windows (2007/XP/Vista/7/8/10) | ||||
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to AVOE.
