P10 6500nits Outdoor Advertising LED Screen 960x960mm Cabients

Basic Information
Place of Origin: Shen Zhen China
Brand Name: AVOE LED
Certification: CE RoHS
Model Number: AE-P10OFRGB
Minimum Order Quantity: 5sqm
Price: Negotiable
Packaging Details: Flight case, Plywood case
Delivery Time: 10 working days after receiving the payment
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 10K sqm per month
Detail Information
Name: Outdoor LED Advertising Screen Pixel Pitch(mm): 10mm
Pixel Density(pixels/㎡): 10000 Pixel/㎡ Module Resolution: 32*16 Pixels
Viewing Angle(deg.): H:140°, V:140° Screen Dimension: Customized Size,960*960
Tube Chip Color: Full Color Display Function: Video,animation,graphics
Brightness: 6500cd/sqm Warranty: 5 Years
Application: Outdoor Advertising Led,Advertising,Outdoor,HOTEL,Advertising/stage Rental/Commercial Event Life Span: 100000 Hours
Module Size: 320x160mm Input Voltage: AC110V - AC240V
High Light:

6500nits Outdoor Advertising LED Screen

,

6500nits Advertising LED Display Screen

,

P10 Outdoor Advertising LED Screen


Product Description

P10 6500nits Outdoor Advertising LED Screen 960x960mm Cabients



LED screen outdoor advertising P10 SMD RGB LED 960x960mm cabients Colorlight cards 6500nits

Description:
(1) Use high quality LED chip and driving chip(), very good quality.
(2) Long life span (100,000 hours).
(3) High brightness, can be use under strong sun shine environment.
(4) Easy maintain.
(5) Working under the temperature -20C to +45C
(6) Low pixel out of control rate, <0.00001
(7) Ingress protection: front IP65, rear IP54.



Applications:
Three in One SMD indoor and outdoor Full Color Display has been specially designed for applications in public information systems, Adverting, Media and Entertainment.
Airports, Border ports, Seaports Railway stations, subways, bus terminals, coach stations
Schools, banks, stock exchanges Stage setting, television studio Hotel lobbies, casinos, disco, bar and so on ....



Parameters
Specification of P10 Outdoor Fixed LED Display
Module
Dimention (w*h) 320x160mm Resolution (w x h) 32x16
Pixel pitch 10mm Pixel Density 10000 dots/㎡
Pixel Configration RGB 3-in-1 LEDs Type SMD3535
Cabinet
Dimensions(w* h)(mm) 960*960mm Module Quantity(PCS) 18
Physical Resolution (w x h) 96*96 Physical Pixels (total) 9216
Weight/Cabinet (kg) 40 Material steel
Average Power/㎡(watts) 300W Max Power/㎡(watts) 800W
Parameter Value
Brightness ≥ 7000 cd/㎡
Viewing Angle Horizontal 140(+70/-70) deg. Vertical 140(+70/-70)deg.
Best Viewing Distance 6-250meters
Brightness Control 256 level
Gray scale 14bits
Refresh frequency ≥ 1920Hz
Driving mode 1/4 scan constant current driving
Input power frequency 50 or 60 Hertz
Input Voltage 110 ~ 240 Volt
Blind spot rate <1/10000
Lifetime at 50% brightness 100000 hours
Ingress Protection IP65/IP54
Operating temperature ﹣20 ~﹢50 ℃
Operating humidity 10% ~ 90%
Control distance CAT6 cable:<100 m; Single mode fiber:<10 km
Signal input format AV, S-Video, VGA, DVI, YPbPr, HDMI, SDI
Operating system Windows (2007/XP/Vista/7/8/10)

P10 6500nits Outdoor Advertising LED Screen 960x960mm Cabients 0P10 6500nits Outdoor Advertising LED Screen 960x960mm Cabients 1P10 6500nits Outdoor Advertising LED Screen 960x960mm Cabients 2P10 6500nits Outdoor Advertising LED Screen 960x960mm Cabients 3
P10 6500nits Outdoor Advertising LED Screen 960x960mm Cabients 4

Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to AVOE.
