Waterproof IP66 1R1G1B P4mm AVOE LED Screen 320x160mm For Advertising

Place of Origin Shen Zhen China
Brand Name AVOE LED
Model Number AE-P4OFRGB
Minimum Order Quantity 5sqm
Price Negotiable
Packaging Details Flight case, Plywood case
Delivery Time 10 working days after receiving the payment
Payment Terms T/T, L/C, Western Union, MoneyGram
Supply Ability 10K sqm per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Certification CE,UL,CCC,ROHS,GS Name Outdoor LED Advertising Screen
Pixel Pitch(mm) 4mm Pixel Density(pixels/㎡) 62500 Pixel/㎡
Pixel Configuration 1R1G1B Viewing Angle(deg.) H:140°, V:140°
Brightness(nits) ≥ 5500 Cd/㎡ Usage Outdoor,subway Station,highway Station Advertising
Screen Dimension Customized Size Tube Chip Color Full Color
Display Function Video,animation,graphics Brightness 6500cd/sqm
Warranty 5 Years Application Outdoor Advertising Led,Advertising,Outdoor,HOTEL,Advertising/stage Rental/Commercial Event
Life Span 100000 Hours Color 1R1G1B
Module Size 256mm*128mm Product Name Led Display Screen
Led Chip Kinglight Input Voltage AC110V - AC240V
High Light

1R1G1B AVOE LED Screen


P4mm AVOE LED Screen


320x160mm Waterproof LED Advertising Screen

Leave a Message
Product Description

HD Waterproof IP66 P4mm AVOE LED screen for advertising outdoor 256*128mm 320x160mm
LED is the abbreviation for light emitting diode. LEDs are arrayed breadthwise and lengthways with stable pitch that form LED matric-LED Display Screen. Each LED of the LED Display has a corresponding luminance control circuit. A computer controls the circuit, the circuit influence the brightness of each LED, then form the picture or letters we desire in the led display screen.

1) High Definition and can be adjusted, can showing DVD, TV, Dynamic images, VCRS, graphs, letters and animations for 24 hours. Sharp, colorful, synchronized with computer monitor. Waterproof, Sun-screen, antistatic, damp proof, anti-freeze, anti-thundering etc.
2) Best equality, commendably solve the problem of the mosaic, have the excellent consistency of light
3) To pictures and character, have clear, exquisite and real display effect of led sign.
4) Big viewing angle to horizontal line and vertical line, can see at every angle at this range, no picture change, no color excursion.
5) Can repair each led lamps, so the cost of maintain is lower, and easy to repair for led sign!



3Pixel Pitch4 mm5 mm6 mm
4LED TypeSMD1921SMD2727SMD3535
6Module Resolution64*32 pixels16*16 pixels16*16 pixels
7Module Size256*128 mm160*160 mm192*192 mm
8Pixel Density62500 pixel/㎡40000 pixel/㎡27777 pixel/㎡
9Refresh Rate≥ 1920Hz≥ 1920Hz≥ 1920Hz
10Gray Scale16 Bit16 Bit16 Bit
11Brightness≥ 5500 cd/㎡≥ 7000 cd/㎡≥ 6000 cd/㎡
12Scan Mode1/81/81/8
13Frame Rate50HZ~60HZ50HZ~60HZ50HZ~60HZ
14Viewing AngleH:140°, V:140°H:140°, V:140°H:140°, V:140°
16Cabinet Resolution192*192 pixels128*128 pixels160*128 pixels
17Cabinet Size768*768*135mm640*640*135mm960*768*135mm
18Cabinet Weight30Kg22Kg40 Kg
19IP RatingFront IP65, Rear IP54Front IP65, Rear IP54Front IP65, Rear IP54
20Max.Power Consumption350W/Panel510W/Panel650W/Panel
21Avg.Power Consumption120W/Panel170W/Panel210W/Panel
22Control SystemNova/LinsnNova/LinsnNova/Linsn
23Operation SystemWindows/me/200NT/XPWindows/me/200NT/XPWindows/me/200NT/XP
25Working Humidity10%~90% RH10%~90% RH10%~90% RH
26Input VoltageAC 110~220 V (±5%)AC 110~220 V (±5%)AC 110~220 V (±5%)
27Blind spot rate≤0.01%≤0.01%≤0.01%
28MTBF35000 Hour35000 Hour35000 Hour
29Lifespan100000 Hour100000 Hour100000 Hour


Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to AVOE.

Waterproof IP66 1R1G1B P4mm AVOE LED Screen 320x160mm For Advertising 0Waterproof IP66 1R1G1B P4mm AVOE LED Screen 320x160mm For Advertising 1Waterproof IP66 1R1G1B P4mm AVOE LED Screen 320x160mm For Advertising 2
