Energy Saving P10 Outdoor Led Display / Large Led Stadium Display stadium led signs

Place of Origin Shen Zhen China
Brand Name AVOE LED
Certification CE RoHS
Model Number AE-P10
Minimum Order Quantity 5sqm
Price Negotiable
Packaging Details Flight case, Plywood case
Delivery Time 10 working days after receiving the payment
Supply Ability 10K sqm per month
Product Details
Name Stadium LED Screens Pixel Pitch 10mm
Pixel Density 10000point/m 2 Brightness 6000cd Cd/m 2
Cabinet Size 960mmx960mmx100mm Application Large Stadium, Waiting Room, TV Live Broadcast
High Light

stadium perimeter led display

,

led stadium advertising boards

Leave a Message
Product Description

Energy Saving P10 Outdoor Led Display / Large Led Stadium Display stadium led signs



Stadium Led Display Introduction:

1. Energy-saving Design : Power consumption is lower than DIP outdoor products, each LED electric current is below 15mA, lifespan is longer, outdoor led advertising screen can reduce 25-50% of the power consumption effectively, low-carbon environmental protection, save electricity for customers .

2. Wide Viewing Angle : LED SMD encapsulation technology, makes surface more smooth, the outdoor full color LED Display can reach 140 degrees viewing angle both in the horizontal and the vertical direction, this has special advantages in some place, such as wall LED Display, requires a wide viewing angle to show better advertising effect.

3. Nice Color Blending : color uniformity is good, outdoor SMD 3-in-i design technology makes all the red, green, and blue chip in one structure, distance is close, so it ensures the coherence of brightness at optional angle is very good, achieve vivid viewing effect, at the same time, the mask is dealt with special processing, can ensure the coherence of product's brightness further.

4. High Definition : High contrast, due to 3-IN-1 design structure, full-color SMD3535 lamp bead size is small, so the light emitting area is small, the black area is large, enhances the contrast of LED Screen, the 1/2 scan mode high refresh rate, the gray level > 16384, the refresh rate > 1200 Hz,makes the outdoor full-color LED Display is clear enough to replace the traditional DIP LED Display.

5. Good Heat Dissipation: using six Angle SMD3535 lamp bead, the heat of lamp and IC can be dispersed by PCB board more effectively, improve the heat dissipation performance of LED display module significantly.

6. High Automation Production Efficiency: SMD LED can be processed by automatic SMT mounter, improving production efficiency, reducing defective product rate.

7. Light Cabinet Weight : Outdoor SMD 3-IN-1 LED uses waterproof glue filling process, because of low lamp foot, don't need too much glue to cover the lamp foot like the DIP, the surface is nice and not deformed easily, assembling is convenient and neat.



Application:Apply to all indoor stadiums, like basketball, volleyball, baseball, ice hokey, etc.



Product specification


Model No. P10
Pixel Pitch 10mm
Pixel Package SMD3535
LED Configuration 1R1G1B
Pixel Density 10000 Pixels/㎡
Module Size 160mm x 160mm
Module Resolution 16 x16 dots
Suggested Cabinet Size 960mm x 960mm x 100mm
Cabinet Resolution 96 x 96 dots
Cabinet Material Iron / Aluminum
Cabinet Weight < 45kg/㎡
Brightness 7000 nits
Color Temperature 3000-12000K
Viewing Angle H-120°/ V-120°
Driving Mode 1/4
Refresh Rate 960-2880Hz
Frame Frenquency 60Hz
Grey Level 4096-16384
Number of Color 1 Billion
Input Maximum Power 530 W/㎡
Input Voltage AC220±10%, AC110 ±10%
Input Frequency 50-60Hz
External Interface S-video, VGA, DVI, SDI, CVBS, YPrPb, HDMI, etc
IP Rating IP65
