P5 football stadium led display / sports led display screen / AVOE led stadium advertising boards

P5 football stadium led display / sports led display screen / AVOE led stadium advertising boards

MOQ: 5sqm
Price: Negotiable
Standard Packaging: Flight case, Plywood case
Delivery Period: 10 working days after receiving the payment
Payment Method: T/T, L/C, Western Union, MoneyGram
Supply Capacity: 10K sqm per month
Detail Information
Place of Origin
Shen Zhen China
Brand Name
AVOE LED
Certification
CE RoHS
Model Number
AE-P5OSTRGB
Name:
Stadium LED Screens
Pixel Pitch:
5mm
Pixel Density/pixels/m²:
10000/m²
Module Size/mm:
320x160
View Distance:
5-400m
Application:
TV Live Broadcast, Exhibition Hall, Performing Arts Center
Highlight:

3840Hz led stadium advertising boards

,

1R1G1B stadium led panel

,

AVOE P5 LED Display

Product Description

P5 football stadium led display / sports led display screen / AVOE led stadium advertising boards



Features



Energy -saving

Easy installation

Environmental protection

High brightness and refresh 3840Hz

Using high reflesh IC, better viewing effect

Passed highest /lowest temperature testing
Larger viewing angle: Horizontal angle 160 degree, Vertical angle 140 degree



Application:
Large stadium, Waiting room, TV live broadcast, Exhibition hall, Performing arts center, Entertainment venue, Large-scale art show, Concert etc.



Product specification

outdoor SMD P5
Resolution/mm 5
Pixel configuration 1R1G1B
Pixel density/pixels/m² 10000/m²
Module resolution 64x32
Module size/mm 320x160
View distance 5-400m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >8000cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/8 scan
Frame rate 60Hz
Refresh frequency >1920Hz
Control mode Computer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted

255 steps. No grey loss

Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Maximum power:/㎡ <1000W
Average power:/㎡ <300W
Self-check technology

LED spot self-check, communications check, power check,

temperature monitor(need customization)

Remote monitoring

Remote supervision and control, record potential fault,

send out warning signs to the operators.(need customization)

Software environment Windows (2007/XP/Vista/7/8/10)
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%

P5 football stadium led display / sports led display screen / AVOE led stadium advertising boards 0P5 football stadium led display / sports led display screen / AVOE led stadium advertising boards 1P5 football stadium led display / sports led display screen / AVOE led stadium advertising boards 2

Competitive Advantages:

1. Good quality;
2. Good price;
3. Good 24hours service;
4. Promote delivery;
5. Energy-saving;
6. Small order accepted.

Our serrvices
1. Service before sales
On-site inspect
Professional design
Solution confirmation
Training before operation
Software use
Safe operation
Equipments maintenance
Installation debugging
Installation guidance
On-site debugging
Delivery Confirmation



2. After sale service
Quick response
Prompt question resolving
Service tracing

3. Service concept:
Timeliness, considerateness, integrity, satisfaction service.
We are always insisting on our service concept, and proud of the trust and reputation from our clients.

4. Service Mission
Answer any question; Deal with all the complaint; Prompt customer service
We had developed our service organization by responding to and meeting the diverse and demanding needs of customers by service mission. We had become a cost-effective, highly skilled service organization.

5. Service Goal:
What you have thought about is what we need to do well; We must and will do our best to fulfill our promise. We always bear this service goal in mind. We can't boast the best, yet we will do our best to free customers from worries. When you get problems, we had already put forward solutions before you.
