P6 Outdoor Fixed LED Display 960x960mm Cabinet Super Wide Viewing Angle

Place of Origin Shen zhen China
Brand Name AVOE LED
Certification CE RoHS
Model Number AV-P6OFRGB
Minimum Order Quantity Negotiable
Price Negotiable
Packaging Details Flight case, Plywood case.
Delivery Time 10 working days after receiving the payment
Payment Terms T/T, Western Union, MoneyGram, L/C
Supply Ability 10K sqm per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Outdoor Fixed Full Color LED Display Resolution/mm 6mm
Pixel Density(pixels/㎡) 27777 Pixel Configuration SMD3535
Viewing Angle(deg.) 160(Horizontal), 160(Vertical) Brightness(nits) ≥7000nits
Highlight

Outdoor Fixed LED Display 7000nits

,

960x960mm Cabinet Outdoor Fixed LED Display

,

RoHS P6 Outdoor LED Display

Leave a Message
Product Description

Super Wide Viewing Angle P6 Outdoor Fixed LED Display, 960x960mm Cabinet, IP65 Protection Grade



Features:

· Uniform color and high contrast ratio,bringing up fresh and natural image
· Low power consumption and fine heat release
· Super wide viewing angle increasing its value by covering more audience
· No deformation under sunlight by the use of anti-UV modules
· Long service time and low attenuation by applying duel channels for heat dissipation
· High protection grade of IP65 achieved by applying duel channels for heat dissipation
· High protection grade of IP65 achieved by patented mask design with waterproot and dustproof fucntion
· Safe and reliable operation ensured by stable signal nad power supply



Aplication:

Supermarkets, home, office, school, warehouse, shopping malls , hospitals ,production line , metro stations etc.





Parameters

Item Value
Pixel Pitch(mm) 6mm
Pixel Density(pixels/㎡) 27777
Pixel Configuration SMD2727/3535
Viewing Angle(deg.) 160(Horizontal), 160(Vertical)
Brightness(nits) ≥7000
Grey Level(bit) 12/14/16
Refresh Rate(Hz) 1920/2880/3840
Cabinet Size(mm) 960(W)×960(H)×130(D)
Cabinet Size(inch) 37.80(W)×37.80(H)×5.1(D)
Cabinet Resolution(pixels) 160×160
Cabinet Material Aluminum/Iron
Weight(kg/㎡) ≤45/≤55
Module Size(mm) 192(W)×192(H)
Module Size(inch) 7.56(W)×7.56(H)
Module Resolution(pixels) 32×32
Protection Grade(Front/Rear) IP65/IP54
Serviceability Front/Rear
Voltage(V) AC 100~AC 240
Avg.Power Consumption(W/㎡) 175(AC)
Max.Power Consumption(W/㎡) 700(AC)
Operating Temp/Humidity(℃/%RH) -20~50/10~90
Storage Temp/Humidity(℃/%RH) -40~60/0~90
Lifetime(Normal Temp)(hours) 100000
Compliant Standard CE FCC RoHS
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to AVOE.


P6 Outdoor Fixed LED Display 960x960mm Cabinet Super Wide Viewing Angle 0P6 Outdoor Fixed LED Display 960x960mm Cabinet Super Wide Viewing Angle 1

P6 Outdoor Fixed LED Display 960x960mm Cabinet Super Wide Viewing Angle 2P6 Outdoor Fixed LED Display 960x960mm Cabinet Super Wide Viewing Angle 3

P6 Outdoor Fixed LED Display 960x960mm Cabinet Super Wide Viewing Angle 4

Installation Procedure

P6 Outdoor Fixed LED Display 960x960mm Cabinet Super Wide Viewing Angle 5

P6 Outdoor Fixed LED Display 960x960mm Cabinet Super Wide Viewing Angle 6P6 Outdoor Fixed LED Display 960x960mm Cabinet Super Wide Viewing Angle 7P6 Outdoor Fixed LED Display 960x960mm Cabinet Super Wide Viewing Angle 8
