P5 SMD2121 Indoor Advertising Led Screen 1000nits Module 320×160mm

Basic Information
Place of Origin: Shen Zhen China
Brand Name: AVOE LED
Certification: CE RoHS
Model Number: AE-INP5
Minimum Order Quantity: 5sqm
Price: Negotiable
Packaging Details: Flight case, Plywood case
Delivery Time: 10 working days after receiving the payment
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 10K sqm per month
Detail Information
Name: Indoor Led Screen Pixels: 5mm
Display Function: Picture Unit Size: 960mmx640mm
Application: Indoor Advertising Color: Full-color
Screen Dimension: 320*160mm Tube Chip Color: Full Color
Usage: Indoor Brightness: 400-1000cd/sqm
Warranty: 3~5 Years Led Chip: Kinglight
Module Size: 320x160mm Life Span: 100000hours,100000 Hours
Product Name: Led Video Display Panel Scan Mode: 1/16 Scan
Refresh Rate: 3840Hz,≥1920 Hz Power Supply: Meanwell
High Light:

SMD2121 Indoor Advertising Led Screen


Indoor Advertising Led Screen 1000nits


320×160mm Indoor Led Display Board

Product Description

SMD2121 P5 indoor advertising led display screen 1000nits module size 320*160mm 1920Hz/ 3840Hz





Model No. P5
Pixel Pitch (mm) 5
LED Configuration SMD2121
Module Size (mm) 320*160
Resolution(dot) 64*32
Pixel Density(dot/㎡) 40000
IP Rating IP30
Scanning Mode 16S
Brightness CD/㎡ 1200
Viewing Angle 160°/ 140°(H/V)
View Distance >3m
Gray 14bit
Color 16.7M
Max/Ave Consumption(W/㎡) 400/130
Refresh Rate(Hz) ≥1920
Gamma Coefficient -5.0~ + 5.0
Application Environment Indoor
Brightness Adjustment 0-100 levels adjustable
Control System Synchronous display with control PC by DVI
Video Format Composite, S-Video,Component, VGA. DVI, HDMI, HD_SDI
Power AC100~240 50/60HZ
Working Temperature -20°C~+50°C
Working Humidity 10~95% RH
Life Span 50,000hours

















































  1. Silent operation with widely viewing angle give you all-around visual enjoyment.
  2. Little attenuation and good heat dissipation protect the product at an large extent.
  3. Driving IC: making the defective phenomena, such as dark bright, virtual light avoidable.
  4. The voltage fluctuation range is less than 5% and the stability is high.
  5. Connector: Ensuring the stable transmission of power and signal.
  6. Easy installation: 100 pieces of cabinets' installation can be finished in one hour by one person.
  7. The replacement of any cabinet can be done within 50 seconds.
  8. This indoor led dancing floor support for interactive function when you touch it by your foot. And all the material is anti-skid and durable to protect dancers and the screen from damage.
