|Place of Origin:||Shen zhen China|
|Brand Name:||AVOE LED|
|Minimum Order Quantity:||5sqm|
|Packaging Details:||Flight case, Plywood case.|
|Delivery Time:||10 working days after receiving the payment|
|Payment Terms:||T/T, Western Union, MoneyGram, L/C|
|Supply Ability:||10K sqm per month|
|Name:||Fixed Full Color LED Display||Resolution/mm:||10mm|
|Pixel Density/pixels/m²:||10000/m²||Module Resolution:||32*16|
|View Distance:||9-400m||Color Temperature:||6500K-9500K|
P10 Outdoor Fixed LED Display,
8000cd/㎡ Outdoor Fixed LED Display,
Magnesium Alloy Outdoor Led Screen
Outdoor SMD P10 Fixed LED display outdoor advertising magnesium alloy Cabinet
● RGB deep grey scale processing, rich color and HD image effect.
● Strong cabinet with reinforcing rib, tensile and quakeproof, with dissipation holes, lifespan more than 10 years.
● Energy saving design, can reduce 25% of consumption, it saves cost for customer, also friendly to the environment.
● Precision, Fast& flexible installation type, can be used in any installation conditions.
● High intensity& anti-aging material, protection level as high as IP65, can resist any bad environment.
● Support dot by dot correction, to make sure the consistency of color and brightness for one screen.
● High quality material, mature craftsmanship, large-scale manufacture and reliable quality.
● Professional navigation connector, keep the safety of whole screen.
Supermarkets, home, office, school, warehouse, shopping malls , hospitals ,production line , metro stations etc.
|White balance brightness||>8000cd/㎡|
|Horizontal view angle||120(degrees)|
|Vertical view angle||60(degrees)|
|Signal Process bit||10 or 16bit|
|Grey process||1024x1024x1024 16834x16834x16834 65536x65536x65536|
|Control distances||CAT6 cable:＜100 m; Single mode fiber:＜10 km|
|Driving mode||Constant driving current|
|Scanning mode||1/4 scan|
|Control mode||Computer synchronous|
|Brightness adjusted range||
Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
|Out of control point||<1/10000|
|Mean Time Between Failure||>5000hours|
|Environment temperature range||Operating temperature range: -20-45℃|
LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
|Software environment||Windows (2007/XP/Vista/7/8/10)|
|Luminous point width between centres||Deviation<3%|
|Color uniformity(chromaticity coordinate)||±0.003|
|Power supply request||AC85-264V(50Hz-60Hz)|
|System protection||Moisture-proof, dust-proof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration|
