High Brightness Dance Floor LED Display Metal Housing 4.81mm Pixel Pitch

Basic Information
Place of Origin: Shen Zhen China
Brand Name: AVOE LED
Certification: CE RoHS
Model Number: AE-P6.25IDRGB
Minimum Order Quantity: 5sqm
Price: Negotiable
Packaging Details: Flight case, Plywood case
Delivery Time: 10 working days after receiving the payment
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 10K sqm per month
Contact Now
Detail Information
Name: Dance Floor LED Display Pixel Pitch: 4.81mm
Pixels: 1R1G1B Brightness (nits): 4500
Load Bearing: 2T Service Access: Front / Rear

Product Description



High Brightness Dance Floor LED Display Metal Housing 4.81mm Pixel Pitch



Outdoor: FO3.9 FO4.6 FO4.8 FO5.2 FO6.2

Indoor: FI3.9 FI4.6 FI4.8 FI5.2 FI6.2



Features



1. Cabinet splicing and wiring connection is fast and reliable. Not only beautiful appearance but also a real sense of the rapid disassembly



2.Adopting quick locking mechanism on the Up, down, left and right connection. Tighten two cabinet up with pull and turn the two handles by 90 degrees



3. Light weight enable one-person installation easier and simpler, save installation time. But traditional HD stage led display is over 25 Kg with the same size



4. Ultra-slim design,metal housing,non-skid treatment toughened glass cover



5. Can be connected with PC and the web net and show the content, and also can be controlled remotely via VPM+ADSL.



6. High brightness and clearly led display effect with easy use control system which allow you easy become enviable led display experts.





Application:Commercial Center, Advertising- Information Publish Board, Commercial Street, Railway Stations, Airports, Bus Stations, Subway, Shopping Malls, Supermarkets, Hospitals, Media Centers Etc.



Parameter

F Series Outdoor FO 3.9 FO 4.6 FO 4.8 FO 5.2 FO 6.2
Pixel Pitch(mm) 3.91mm 4.625mm 4.81mm 5.2mm 6.25mm
Pixel Matrix Per Sq.m 65536 46656 43264 36864 25600
Pixel Configuration SMD1921 SMD2727 SMD2727 SMD2727 SMD2727
Brightness (nits) 4000 4500 4500 4500 5000
Scan 1/16 1/13 1/13 1/10 1/10
Cabinet Resolution 128×128 108×108 104×104 96×96 80×80
Power Con. (Max/Avg) 750/230 w/sq.m 730/220 w/sq.m 700/220 w/sq.m 710/210 w/sq.m 710/210 w/sq.m
Module Dimension 250x250mm / 0.82x0.82ft
Cabinet Dimension 500x500x80mm / 1.64x1.64x0.26ft
Cabinet Weight 10kg / ( Die-casting Aluminum)
Service Access Front / Rear
Load Bearing 2T
Refresh Rate (HZ) 1920
Grey Scale (bit) 16
Viewing Angle (H/V) 140 / 140
IP Rate IP65
Input Voltage (AC) 110 / 240

Specifications and photos are subject to change without prior notice.





Detailed

Detailed



Interactive Floor LED Display

Special driving IC built inside the LED display PCB will work together with interactive control system.
It will easily and quickly make you interesting and attractive between the players and display.Non Skid Dance Floor Led Screen , Front Service Led Display Light Weigh P6.25


Anti-skid, Anti-knock, Anti-glare Mask

Anti scratch Mask with HI-density PC



High Load Bearing with 2T weight

Non Skid Dance Floor Led Screen , Front Service Led Display Light Weigh P6.25

Easy Installation and Maintenance

Non Skid Dance Floor Led Screen , Front Service Led Display Light Weigh P6.25

Non Skid Dance Floor Led Screen , Front Service Led Display Light Weigh P6.25Non Skid Dance Floor Led Screen , Front Service Led Display Light Weigh P6.25

Two Floor Standing Solutions

Base Support



Rail Support



All weather Resistance

LEDFUL floor LED display outdoor series is all weather resistance. For indoor series, the front side is waterproof.
