Front / Rear Serviceability 4mm Led Display , Led Advertising Display 1200nits

Basic Information
Price: Negotiable
Contact Now
Detail Information
Name: LED Display Screen Pixel Pitch(mm): 4
Brightness(nits): 1200 Serviceability: Front/Rear
Panel Dimension(mm): 576(W)x576(H) Panel Type And Material: Die-casting Aluminum

Product Description

Front / Rear Serviceability 4mm Led Display , Led Advertising Display 1200nits



Description



This product designed with die-casting aluminum, which makes it more stable and effective.good intensity

Lightweight makes it easy to operate and install.

The special splicing design realizes a variety of styles, so that the products meet the diverse requirements of customers.

Our products perform well in waterproof, antifreeze and high temperature resistance.



The product has been passed the dust-proof and water-proof, achieving protection standards IP43.



All module edges have made strong compression, which makes the cabinet have better flatness and is not easily deformed.



The box with a sliding iron top, bottom chute, and optional locking device to fine-tune the gap and ensure seamless between the boxes. Please do not squeeze the entire screen which ensure good surface smoothness





Widely applications:
Mainly used to do outdoor advertisement just like TV, in addition, it also can be used to play the Events, Showing, Cinema, Sports, etc.



Parameters

Item Value
Pixel Pitch(mm) 4
Pixel Density(pixels/㎡) 62500
Viewing Angle(Deg.) H: 160/ V: 160
Brightness(nits) 1200
Grey Level(bit) 12/14/16
Refresh Rate(Hz) 1920/2880/3840
Panel Dimension(mm) 576(W)x576(H)
Panel Dimension(inch) 22.68(W)x22.68(H)
Panel Resolution(pixels) 144x144
Panel Type and Material Die-casting aluminum
Panel Weight(kg) 11
Module Size(mm) 288(W)x288(H)
Module Size(inch) 11.34(W)x11.34(H)
Protection Grade IP30
Serviceability Front/Rear
Avg.Power Consumption(W/㎡) 143(AC)
Max.Power Consumption(W/㎡) 570(AC)
Brightness Adjustment Manual/Auto/Programmable
Operating Temp/Humidity(℃/%RH) -20~+50/10~90
Storage Temp/Humidity(℃/%RH) -40~+60/0~90
Lifetime(hours) 100000(Nomal Temp)
Compliant Standard CE,FCC,RoHS
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to AVOE.
