High Definition P4mm Indoor Fixed LED Display , Stage LED Video Wall Display Vivid Colors

Place of Origin Shen Zhen China
Brand Name AVOE LED
Certification CE RoHS
Model Number AE-P4
Minimum Order Quantity 5sqm
Price Negotiable
Packaging Details Flight case, Plywood case
Delivery Time 10 working days after receiving the payment
Payment Terms T/T, L/C, Western Union, MoneyGram
Supply Ability 10K sqm per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name LED Display Screen Pixel Pitch(mm) 4mm
Brightness(nits) 1200 Pixel Density(pixels/㎡) 62500
Feature High Brightness, High Definition Applications The Events, Showing, Cinema
Screen Dimension 320*160mm,256mm X 128mm Tube Chip Color Full Color
Usage Indoor Display Function Video,text,message,image,picture
Brightness 1500nits Warranty 3~5 Years
Led Chip Epistar,Kinglight,Silan Module Size 320x160mm
Life Span 100000hours Application Indoor Advertising,video Commercial Ad,publicity
Product Name Led Video Display Panel Color 1R1G1B,Full-color,Full Color,RGB
Scan Mode 1/16 Scan Refresh Rate ≥1920 Hz
High Light

commercial led display screen

,

indoor led advertising screen

Leave a Message
Product Description

High Definition P4mm Indoor Fixed LED Display , Stage LED Video Wall Display Vivid Colors



Features:

Lightweight, space-saving and labour-saving.

Nice appearance and simple structures.

Quick locking methods design makes no other tools installation available.

With indicator lights and backside flexible door, easy to test and maintain.

High refresh rate with HD video performance.

Front maintenance solution with magnetic led module, you can take all components from front.

Adopted high quality LED chip to achieve 4000:1 contrast which ensure higher image quality with

vivid colors and high gray level.

All the indoor led video wall is energy saving design and noiseless. It is very suitable

for meeting room, court, church, shopping mall, monitoring room, TV studio, etc.

The DIP technology reduced the grainy of the screen, and improve the uniform of it, which makes the screen have a wide viewing angle and smooth image.

It adopted advanced technology, so that it can keep the high brightness .



Widely applications:
Mainly used to do outdoor advertisement just like TV, in addition, it also can be used to play the Events, Showing, Cinema, Sports, etc.



Parameters

Item Value
Pixel Pitch(mm) 4mm
Pixel Density(pixels/㎡) 62500
Viewing Angle(Deg.) H: 160/ V: 160
Brightness(nits) 1200
Grey Level(bit) 12/14/16
Refresh Rate(Hz) 1920/2880/3840
Panel Dimension(mm) 640x640mm

Panel Resolution(pixels) 160x160
Panel Type and Material Die-casting aluminum
Panel Weight(kg) 11
Module Size(mm) 320(W)x160(H)
Module resolution(pixel) 80x40
Protection Grade IP30
Serviceability Front/Rear
Avg.Power Consumption(W/㎡) 143(AC)
Max.Power Consumption(W/㎡) 570(AC)
Brightness Adjustment Manual/Auto/Programmable
Operating Temp/Humidity(℃/%RH) -20~+50/10~90
Storage Temp/Humidity(℃/%RH) -40~+60/0~90
Lifetime(hours) 100000(Nomal Temp)
Compliant Standard CE,FCC,RoHS
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to AVOE.

High Definition P4mm Indoor Fixed LED Display , Stage LED Video Wall  Display Vivid Colors 0High Definition P4mm Indoor Fixed LED Display , Stage LED Video Wall  Display Vivid Colors 1High Definition P4mm Indoor Fixed LED Display , Stage LED Video Wall  Display Vivid Colors 2
