Energy Saving P6.67 Stage Rental LED Display 640*640mm Cabinet For TV Shows Front & Rear Mainterance

Place of Origin Shen Zhen China
Brand Name AVOE LED
Certification CE RoHS
Model Number AE-P6.67ISRGB
Minimum Order Quantity 5sqm
Price Negotiable
Packaging Details Flight case, Plywood case
Delivery Time 10 working days after receiving the payment
Payment Terms T/T, L/C, Western Union, MoneyGram
Supply Ability 10K sqm per month
Product Details
Name Stage Rental LED Display Pitch 6.67mm
Pixel Density 22478 Pixels/m2 LED Configuration 1R1G1B
Cabinet Material Die Casting Aluminum Application Music Venues And Concerts
Tube Chip Color Full Color Usage Indoor,Outdoor
Display Function Video,Animation,advertising Screen Dimension Customized Size
Brightness 6000nit Warranty 3~5 Years
Life Span 100000 Hours Module Size 320x160mm
Product Name Led Video Display Panel Led Chip Epistar,Nationstar
Color Full Color,1R1G1B Cabinet Material Die Casting Aluminum,magnesium & Aluminum Alloy
Pixel Configuration SMD 3IN1
High Light

stage background led screen

,

led screen stage backdrop

Leave a Message
Product Description

Energy Saving P6.67 Stage Rental LED Display 640*640mm Cabinet For TV Shows Front & Rear Mainterance



Features :



1 . Magnet adsorption. LED modules magnetically adsorb on the frame, tool freely remove without power-cut.


2 . Front & Rear mainterance(without any tooling). LED modules and control box can be cross over the panel frame easily.


3 . Control box integrates receiving card(HUB card),power supply and cables, for quick replacement and later maintenance.


4 . Modules can be laid discretionarily, no distinction on order.


5 . Frame supports different model(pixel pitch) of modules, increasing the investment return by 30%.


6 . The outer lines can be through the side of the panels, tider.


7 . Double strengthing ribs design on the back and sides, sturdy structure(against deformation).


8 . The mask flat surface is 0.2mm higher than the LEDs, furthest increasing the viewing angle and protecting the LEDs.



Application





1 : Shopping Malls



2 : Music Venues and Concerts



3 : Theater and Arts



4 : TV Shows



Product Parameters




Pixel Pitch 6.67mm
Pixel Density 22478 pixels/m2
LED Type SMD3535
LED Configuration 1R1G1B
Cabinet Dimension 640mmx640mm
Cabinet Resolution 96*96pixels
Cabinet Weight 13kg
Cabinet Material die casting aluminum
Ingress Protection(front/rear) IP65/IP54
Brightness >6500nits
Viewing Angle(H/V) 140°/140°
Driving Method 1/6 Scan
Frame Refresh ≥ 60Hz
Data Refresh Rate >1500Hz
Gray Scale 16bit
Power Consumption(avg.) 300w/m2
Input Voltage AC 110/220±10%, 50~60Hz
Temperature(operating/storage) -20~50°C / -40~60°C
Humidity(operating/storage) 10%~90%RH / 10%~85%RH
MTBF ≥1000hrs
Life Span ≥100000hrs
Pixel Failure <0.0003



Energy Saving P6.67 Stage Rental LED Display 640*640mm Cabinet For TV Shows Front & Rear Mainterance 0Energy Saving P6.67 Stage Rental LED Display 640*640mm Cabinet For TV Shows Front & Rear Mainterance 1Energy Saving P6.67 Stage Rental LED Display 640*640mm Cabinet For TV Shows Front & Rear Mainterance 2Energy Saving P6.67 Stage Rental LED Display 640*640mm Cabinet For TV Shows Front & Rear Mainterance 3Energy Saving P6.67 Stage Rental LED Display 640*640mm Cabinet For TV Shows Front & Rear Mainterance 4
