1R1G1B 1200nits Indoor Smd Led Display 1/16 Scan P4 320x160mm Module

Place of Origin Shen Zhen China
Brand Name AVOE LED
Certification CE RoHS
Model Number AE-INP4
Minimum Order Quantity 5sqm
Price Negotiable
Packaging Details Flight case, Plywood case
Delivery Time 10 working days after receiving the payment
Payment Terms T/T, L/C, Western Union, MoneyGram
Supply Ability 10K sqm per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name LED Display Screen Pixel Pitch(mm) 4
Brightness(nits) 1200 Pixel Density(pixels/㎡) 62500
Viewing Angle(Deg.) H: 160/ V: 160 Protection Grade IP30
Tube Chip Color Full Color Usage Indoor
Display Function Video,text,message,image,picture Brightness 400-1000cd/sqm
Warranty 3~5 Years Led Chip Kinglight
Module Size 320x160mm Life Span 100000hours,100000 Hours
Application Indoor Advertising,video Commercial Ad,publicity Product Name Led Video Display Panel
Color 1R1G1B,Full Color,RGB Scan Mode 1/16 Scan
Refresh Rate 3840Hz,≥1920 Hz Power Supply Meanwell
High Light

1200nits Indoor Smd Led Display

,

1R1G1B Indoor Smd Led Display

,

320x160mm Module Indoor Led Screen

Leave a Message
Product Description

1/16 scan 3840Hz LED display P4 indoor screen 1200nits 320x160mm module size



Features:



1. High definition and could be adjusted, so it can meet the request of the customers according the application environments



2. Wide application, good for rental or fixed installation



3. Adopt high-intensity aluminum, has a better anti-rust and corrosion resistant capacity



4. with 10KG in weight and 70mm in thickness. Common cabinet with 20KG in weight and thickness with 100mm



5. 48 hours for led module test and 72 hours for led screen test to ensure the perfect quality.

Work temperature -20~+40 deg



6. Professional lock design makes seamless connection available



7. High gray scale and stable performance,realize the HD and exquisite image



Widely applications:
Mainly used to do outdoor advertisement just like TV, in addition, it also can be used to play the Events, Showing, Cinema, Sports, etc.



Parameters





Model No. P4-A P4-B P4-C
Pixel Pitch (mm) 4 4 4
LED Configuration SMD2121 SMD2121 SMD2121
Module Size (mm) 320*160 256*256 256*128
Resolution(dot) 80*40 64*64dot 64*32
Pixel Density(dot/㎡) 62500 62500 62500
IP Rating IP30 IP30 IP30
Scanning Mode 20S 32S 16S
Brightness CD/㎡ 1000 1000 1000
Viewing Angle 160°/ 140°(H/V) 160°/ 140°(H/V) 160°/140°(H/V)
View Distance >3m >3m >3m
Gray 14bit 14bit 14bit
Color 16.7M 16.7M 16.7M
Max/Ave Consumption(W/㎡) 550/200 460/160 480/170
Refresh Rate(Hz) ≥1920 ≥1920 ≥1920
Gamma Coefficient -5.0~ + 5.0 -5.0~+5.0 -5.0~+5.0
Application Environment Indoor Indoor Indoor
Brightness Adjustment 0-100 levels adjustable
Control System Synchronous display with control PC by DVI
Video Format Composite, S-Video,Component, VGA. DVI, HDMI, HD_SDI
Power AC100~240 50/60HZ
Working Temperature -20°C~+50°C
Working Humidity 10~95% RH
Life Span 50,000hours
