Dust Proof Sport Perimeter LED Display Easy Maintenance Good Color Uniformity

Basic Information
Place of Origin: Shen Zhen China
Brand Name: AVOE LED
Certification: CE RoHS
Model Number: AE-P6.67OPRGB
Minimum Order Quantity: 5sqm
Price: Negotiable
Packaging Details: Flight case, Plywood case
Delivery Time: 10 working days after receiving the payment
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 10K sqm per month
Contact Now
Detail Information
Name: Sport Perimeter LED Display Pixel Pitch (mm): 16mm
Pixel Matrix Per Sq.m: 3906 Pixel Configuration: SMD3535
Brightness (nits): 8000 Service Access: Front / Rear

Product Description

Dust Proof Sport Perimeter LED Display Easy Maintenance Good Color Uniformity



Stadium perimeter LED display's Advantages:

1. Double data backup: if one data cable doesn’t work, perimeter led display still can work well;

2. Rubber mask: The rubber mask can protect football player and also protect led display itself;

3. Adjustable bracket at the back of cabinet;
4. Good color uniformity, because we use top rate of Led;
5. Energy saving, due to we use high efficiency power supply, top rate of led, etc;

6. Good waterproof protection: Front is IP65 and back is IP54;

7.Foam protector on the top of cabinet can also protect players ;



Our service



1. Your inquiry related to our products or price will be replied in 24hrs

2. OEM&ODM, any your customized requirement we can help you to design and put into product

3. Distributorship are offered for your unique design and some our current models

4. Protection of your sales area, ideas of design and all your private information

5. Top quality+Reasonable price+Responsible After Service=Successful & Win

6. Bakovision can offer you LED stage display, LED outdoor video wall, wedding LED display, stage LED electronic screen and led large screen full color display.



Specification

Indoor / Outdoor PM IPM6 IPM10 OPM8 OPM10 OPM16
Pixel Pitch(mm) 6 10 8 10 16
Pixel Matrix Per Sq.m 27777 10000 15625 10000 3906
Pixel Configuration SMD3528 SMD3528 SMD3535 SMD3535 SMD3535
Brightness (nits) 2200 1800 6800 7500 8000
Scan 1/8 1/4 1/3 1/2 1/1
Module Dimension 192x192mm/0.63x0.63ft 320x160mm/1.05x0.52ft 320x160mm/1.05x0.52ft 320x160mm/1.05x0.52ft 256x256mm/0.84x0.84ft
Cabinet Dimension 960x960mm/3.15x3.15ft 1280x960mm/4.2x3.15ft 1280x960mm/4.2x3.15ft 1280x960mm/4.2x3.15ft 1024x1024mm/3.36x3.36ft
Cabinet Resolution 160x160 128x96 160x120 128x96 64x64
Cabinet Weight 40kg / 88Ib (Iron) 44kg / 97Ib (Iron) 49kg / 108Ib (Iron) 48kg / 105Ib (Iron) 46kg / 101Ib (Iron)
Power Con. (Max / Avg) 550 / 100 w/sq.m 500 / 90 w/sq.m 680 / 120 w/sq.m 650 / 110 w/sq.m 690 / 130 w/sq.m
IP Rate IP43 IP65
Service Access Front / Rear Front / Rear
Refresh Rate (HZ) 2880 ≥2880
Grey Scale (bit) 14bit 16bit
Viewing Angle (H/V) 140 / 140 140 / 140
Input Voltage (AC) 110V / 240V 110V / 240V



Detailed:

Solid, Compact, Strong Cabinet Design For All Weather and Prevent for Any External Attacks

Dust Proof Sport Perimeter LED Display Easy Maintenance Good Color Uniformity

Dust Proof Sport Perimeter LED Display Easy Maintenance Good Color Uniformity

Rotating Design with Wheels for Emergency Exit

PM series with rotating base and wheels for emergency exit for perimeter LED display installation in stadium.
This is necessary for quick and easy escape required by most football associations.

Dust Proof Sport Perimeter LED Display Easy Maintenance Good Color Uniformity

Adjustable Bracket

Cabinet adjustable angle between 60°and 90°

Dust Proof Sport Perimeter LED Display Easy Maintenance Good Color Uniformity

Protective Top Cover and Rubber Module Mask

Protective top cover protect players from injury. Rubber module mask protect LED from ball and players striking,
besides protect players against further injury.

Dust Proof Sport Perimeter LED Display Easy Maintenance Good Color Uniformity

Independent RCD Protection

RCDs protect the system against short circuits, overcurrent and leakage currents which makes the system absolutely safe to operate.

Dust Proof Sport Perimeter LED Display Easy Maintenance Good Color Uniformity

Professional Software PM Player

LEDFUL PM Player and software makes it easy to control your screen,
manage your media and show linear content on your perimeter LED display, which is friendly for advertising application.

Dust Proof Sport Perimeter LED Display Easy Maintenance Good Color Uniformity

4H Makes Perfect Visual Effect

· High Brightness: ≥7000nits · High Grey Scale: 65536 levels
· High Refresh Rate: 2880Hz · High Contrast: 5000:1

Dust Proof Sport Perimeter LED Display Easy Maintenance Good Color Uniformity
Dust Proof Sport Perimeter LED Display Easy Maintenance Good Color Uniformity

SMD Performance and View Angle

Better contrast ratio and viewing performance
Wide viewing angle increasing its value by covering more viewing

Dust Proof Sport Perimeter LED Display Easy Maintenance Good Color Uniformity

Energy Saving Stadium Perimeter
LED Display

1) Using high efficiency IC driver
2) improved PCB design
3) Power conversion efficiency

Dust Proof Sport Perimeter LED Display Easy Maintenance Good Color Uniformity

Backup for Recycle

Dust Proof Sport Perimeter LED Display Easy Maintenance Good Color Uniformity
